Loader joystick kit

Loader joystick kits are widely used in hydraulic systems in for example agriculture, horticulture, forestry, construction, broadly understood industry and many more.

Loader joystick kit is adapted to various types of construction machines such as: agricultural machines, tractors, sprayers, rounds, cyclops, HDS loaders, loaders, excavators, sweepers, industrial machines and other hydraulically controlled devices where the hydraulic pump capacity does not exceed limit of 40 L / min.

The loader joystick kit is designed for precise work in machines with a fixed pressure system, where one pump supplies both the steering system called orbitrol and the hydraulic system in the loader in most loaders.

Joystick control brings many advantages that make work faster, more pleasant, safe and precise. The joystick is above all a more comfortable, convenient and precise machine control. The mechanism enabling blocking movements of the joystick handle is a significantly increased safety of the operator and people who may be in the vicinity of the loader.

The assembly of the joystick inside the cabin and the discharge of the manifold outside makes the cabin clean and without oil leaks which bring only pleasure for the worker.

Suitable for mechanical control of two sections in the manifold. Internal aluminum construction elements and the housing made of strong strengthened plastic. Additionally you can find of course blocking button for safety and crisis situations. Cable length in the standard 2m and there is the ability to change the length of the links if you want to. Another advantage are the threads from the distributor side.

Both three-position sliders (1 - 0 - 2) on the spring.

They return themselves to the neutral position if the cable is loose.
Position 0 neutral when the cable is loose and cylinder piston is standing - oil goes on transfer.

Working position number 1 with the rope pulls the slider and the piston rod extends.

Position 2 when rope pushes the slider and cylinder piston hides.
